AliDeck Aluminium Decking XL Board

The AliDeck XL Decking Board is our ultra-wide spanning non-combustible aluminium deck board, tailor-made for steel balcony fabricators and to reduce the need for expensive steel beams in the balcony framework. With a depth of 60mm XL Board is our largest-spanning board, achieving a huge 1800mm between supports. Accordingly, we are confident the XL Board is the largest-spanning extruded board available for balcony decking in the UK.

The AliDeck XL Board has been designed as a quick-fit solution for easy installation, delivers second-to-none span of up that is compliant with BS8579:2020 (2.0kN point load with maximum allowable deflection of 5mm), has a fully aluminium construction, is fire resistant and comes with our 30-year manufacturer warranty.

1,800mm

Maximum Span

60mm

Board Depth

120mm

Board Width

3.09KG/lm

Board Weight

4.46mm

BS8579 Deflection

30 Years

Product Warranty

60 Years

Expected Lifespan

67%

Recycled Content

XL Board Datasheet, CAD & DWG Files

Testing Report and Installation Guide

Standard Colours

  • Confirm colour selection with a RAL colour swatch before purchase. Any non-standard RAL colour available on request as special order

Woodgrain Colours

Fire Resistant Aluminium Metal Decking for Balconies, Terraces and Walkways with the AliDeck XL Board

AliDeck XL board 2000mm span
  • Dimensions:
    Length: 4 metres & 6 metres | Width: 120mm | Depth: 60mm
    Maximum Overall Decking Area: Unlimited
    Allowable Span: 1800mm to meet BS8579:2020

Installation
Speed and ease of installation are key to any project, so we have designed a board that has a unique invisible (structural) top clip system which can be installed from the top down. The board can also be trimmed down the length to match any projection of balcony and still be structurally stable across the whole plank. The boards can be cut to size along both the length and width.

The AliDeck Aluminium decking boards are 50% quicker to install compared to other decking systems on the market. These boards are fixed from the top down so requires no fancy, fiddly fixings.

Drainage

They can also be spaced to allow for varying drainage requirements (unlike any other system).

Aesthetics

Aesthetics are key to a great finish; our boards are designed to look like decking but not to feel like aluminium.

Warranty

The decking is supplied with a 30 year warranty against splitting, cracking, warping, splintering, rotting, twisting and material or manufacturing defects. It has a minimum 60 year life expectancy.

Systemisation

All AliDeck aluminium decking boards are fully compatible with all AliDeck Joists.

Construction

The boards are constructed completely from 100% aluminium (6063 T6 grade), up to 67% of which has been recycled to make these boards eco-friendly and much better for the environment.

Maintenance

AliDeck’s aluminium decking, finished with a 7-stage Qualicoat system, requires minimal maintenance. A quick wipe with a damp lint-free cloth is enough. Our superior class 2 powder coating exceeds industry standards, ensuring lasting quality with less upkeep.

Protective Finish

The planks are coloured using the Qualicoat powder coating finish. Qualicoat is a quality label organisation committed to maintaining and promoting the quality of coating on aluminium and its alloys for architectural applications.

Colour Options

The decking boards are available in the full AliDeck range of Qualicoat powder-coat colours.
